Product Description
Product Overview
|
Category |
Details |
|---|---|
|
Manufacturer |
Honeywell |
|
Model/Part Number |
CP-DYNA-2AIO |
|
Description |
Analog Input/Output Module designed for Honeywell Distributed Control Systems, supporting 16 configurable analog I/O channels. Ideal for process control applications. |
Key Features
-
16 configurable analog input/output channels
-
Supports 4–20 mA signal types
-
Compatible with Honeywell C300 controller
-
High-resolution data conversion
-
Seamless integration with Experion PKS and ControlEdge
-
Reliable and robust operation in industrial environments
Technical Specifications
|
Specification |
Details |
|---|---|
|
Model |
CP-DYNA-2AIO |
|
Product Type |
Analog Input/Output Module |
|
Series |
Experion PKS, ControlEdge |
|
Number of Channels |
16 (analog, configurable as input or output) |
|
Signal Type |
4–20 mA (typical) |
|
Power Supply |
24 VDC (via system backplane) |
|
Operating Temperature |
-40°C to 70°C (-40°F to 158°F) |
|
Weight |
Approx. 0.3–0.5 kg (0.66–1.1 lbs) |
External Connection Options
|
Connection Type |
Details |
|---|---|
|
Supported Connections |
Terminal blocks for field wiring Connects to C300 controller via IOTA (Input/Output Termination Assembly) |
Functional Features
|
Feature |
Details |
|---|---|
|
Signal Processing |
Converts analog signals to digital values for accurate monitoring and control |
|
Compatibility |
Fully integrates with Honeywell Experion PKS and C300 controllers |
|
Reliability |
Engineered for durability in demanding industrial conditions |
|
Configuration |
Configurable using Experion Control Builder software |
Model and Configuration
|
Category |
Details |
|---|---|
|
Base Model |
CP-DYNA-2AIO |
|
Configuration |
Standard module for 16-channel analog I/O |
