Product Description
Honeywell 51404459-001 Cable Assembly
Product Overview
- The Honeywell 51404459-001 is a Cable Assembly designed for use in Honeywell’s Distributed Control Systems (DCS), including the TDC 3000 and Experion Process Knowledge System (PKS) platforms. This cable facilitates reliable connectivity between system components, such as Input/Output (I/O) modules, controllers, or termination assemblies, ensuring robust data and signal transmission in industrial automation applications. It is commonly used in industries like oil and gas, chemical, and manufacturing where dependable communication is critical.
Technical Specifications
- The 51404459-001 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 51404459-001 |
| Manufacturer | Honeywell |
| Description | Cable Assembly for DCS Systems |
| Series | TDC 3000 / Experion PKS |
| Cable Type | Multi-conductor, shielded (specific configuration may vary) |
| Connector Type | Typically proprietary Honeywell connectors (e.g., for I/O modules) |
| Length | Variable (commonly 1 to 10 meters, depending on application) |
| Voltage Rating | Low voltage (typically up to 24 VDC) |
| Operating Temperature | -20°C to +60°C (-4°F to +140°F) |
| Weight | Approx. 0.1 to 0.5 kg (depending on length) |
Additional Details
- The 51404459-001 includes the following additional information based on its standard use and documentation:
- Function: Ensures reliable signal and data transmission between DCS components, such as connecting Field Termination Assemblies (FTAs) to Input/Output Processors (IOPs) or controllers.
- Mounting: Not mounted; used as a flexible interconnect between system modules, often with plug-and-play connectors for easy installation.
- Compatibility: Compatible with Honeywell’s TDC 3000 and Experion PKS systems; typically used with modules like MC-TAIH12, MC-TDIA12, or other UCN components.
- Configuration: Designed for specific system configurations; may include shielding to reduce electromagnetic interference in industrial environments.
- Certifications: Meets CE, UL, and ATEX standards for industrial environments (where applicable).
