Product Description
🔹 General Information
|
Manufacturer |
Yokogawa |
|---|---|
|
Model/Part Number |
NFJT100-S100 |
|
Description |
FCJ Autonomous Controller – Basic Type, Without Fieldbus Interface, With I/O, No Explosion Protection |
🔹 Technical Specifications
|
Item |
Specification |
|---|---|
|
Model |
NFJT100-S100 |
|
Weight |
1.7 kg |
|
Power Supply |
24 V DC ±10% |
|
Current Dissipation |
800 mA |
|
Dimensions (W x H x D) |
213.8 x 156 x 95 mm |
|
Analog Inputs (AI) |
6 channels |
|
Analog Outputs (AO) |
2 channels |
|
Digital Inputs (DI) |
16 channels |
|
Digital Outputs (DO) |
16 channels |
|
Control Network |
Ethernet (supports duplex configuration) |
|
Fieldbus Support |
Not supported in this model |
|
Mounting |
Panel-mounted or DIN rail-mounted |
🔹 Model & Suffix Code Configuration
|
Model |
Description |
|---|---|
|
NFJT100 |
FCJ Autonomous Controller |
Suffix Codes
|
Suffix |
Description |
|---|---|
|
-S |
Without Foundation Fieldbus interface |
|
1 |
With I/O: AI (6), AO (2), DI (16), DO (16) |
|
0 |
Always 0 |
|
0 |
Basic type with no explosion protection |
