Yokogawa NFCP502-W05 CPU Module for FCN (with 4 Ethernet ports)

Yokogawa NFCP502-W05 CPU Module for FCN (with 4 Ethernet ports)

  • Manufacturer: Yokogawa

  • Product No.: NFCP502-W05

  • Condition:100 in stock

  • Product Type: CPU Module for FCN

  • Product Origin: JAPAN

  • Payment: T/T, Western Union

  • Weight: 520g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

The Yokogawa NFCP502-W05 is a high-performance CPU module designed for FCN systems, featuring four Ethernet ports and extended functions. It is ideal for real-time control applications requiring robust processing, redundancy, and high-speed communication.

Product Overview

  • Manufacturer: Yokogawa
  • Product No.: NFCP502-W05
  • Product Type: CPU Module
  • Model: NFCP502 – CPU module for FCN (with 4 Ethernet ports)
  • Suffix Codes:
    • W: With extended functions (1)
    • 0: Standard type
    • 5: Basic type with no explosion protection

Technical Specifications

Processing & Memory

  • Processor: Intel Atom E3815, 1.46 GHz
  • Main Memory: 256 MB with ECC
  • Static RAM: 2 MB with ECC, battery-backed
  • Secondary Memory: 1 GB on-board flash memory
  • External Storage: SD card slot (SDHC, 4 to 32 GB, Class 10)

Communication Interfaces

  • Serial Port (1): 1 x RS-232-C (D-sub 9 pins, male) (2)
    • Baud Rate: 0.3, 1.2, 2.4, 4.8, 9.6, 14.4, 19.2, 28.8, 38.4, 57.6, or 115.2 kbps
    • Communication: Full/Half duplex (software settings)
    • Synchronization: Asynchronous
  • Network Interface: 4 x Ethernet Ports (RJ45 modular jacks)
    • Baud Rate: 1000, 100, 10 Mbps (1000BASE-T, 100BASE-TX, 10BASE-T)

I/O & Power

  • I/O Interface: SB bus (duplex)
  • Supply Voltage: 5 V DC ±5%
  • Current Consumption: Max. 1700 mA

Reliability & Features

  • RAS Features: Watchdog timer, temperature monitor, etc.
  • Battery (3): 1000 mAh graphite fluoride lithium battery (4)
  • Protection: CPU cover (with hole for wire lock)
  • Display LEDs:
    • 3 LEDs for CPU status
    • 2 LEDs for Ethernet status
    • 1 LED for SD card activity
    • 1 LED for EXEC status
  • Switches:
    • RESET switch
    • SHUTDOWN switch
    • FUNC switch
    • EXEC switch

The Yokogawa NFCP502-W05 is a reliable and high-performance CPU module, making it a versatile choice for industrial control applications requiring high-speed networking and robust processing power.

View full details

Product Description

The Yokogawa NFCP502-W05 is a high-performance CPU module designed for FCN systems, featuring four Ethernet ports and extended functions. It is ideal for real-time control applications requiring robust processing, redundancy, and high-speed communication.

Product Overview

  • Manufacturer: Yokogawa
  • Product No.: NFCP502-W05
  • Product Type: CPU Module
  • Model: NFCP502 – CPU module for FCN (with 4 Ethernet ports)
  • Suffix Codes:
    • W: With extended functions (1)
    • 0: Standard type
    • 5: Basic type with no explosion protection

Technical Specifications

Processing & Memory

  • Processor: Intel Atom E3815, 1.46 GHz
  • Main Memory: 256 MB with ECC
  • Static RAM: 2 MB with ECC, battery-backed
  • Secondary Memory: 1 GB on-board flash memory
  • External Storage: SD card slot (SDHC, 4 to 32 GB, Class 10)

Communication Interfaces

  • Serial Port (1): 1 x RS-232-C (D-sub 9 pins, male) (2)
    • Baud Rate: 0.3, 1.2, 2.4, 4.8, 9.6, 14.4, 19.2, 28.8, 38.4, 57.6, or 115.2 kbps
    • Communication: Full/Half duplex (software settings)
    • Synchronization: Asynchronous
  • Network Interface: 4 x Ethernet Ports (RJ45 modular jacks)
    • Baud Rate: 1000, 100, 10 Mbps (1000BASE-T, 100BASE-TX, 10BASE-T)

I/O & Power

  • I/O Interface: SB bus (duplex)
  • Supply Voltage: 5 V DC ±5%
  • Current Consumption: Max. 1700 mA

Reliability & Features

  • RAS Features: Watchdog timer, temperature monitor, etc.
  • Battery (3): 1000 mAh graphite fluoride lithium battery (4)
  • Protection: CPU cover (with hole for wire lock)
  • Display LEDs:
    • 3 LEDs for CPU status
    • 2 LEDs for Ethernet status
    • 1 LED for SD card activity
    • 1 LED for EXEC status
  • Switches:
    • RESET switch
    • SHUTDOWN switch
    • FUNC switch
    • EXEC switch

The Yokogawa NFCP502-W05 is a reliable and high-performance CPU module, making it a versatile choice for industrial control applications requiring high-speed networking and robust processing power.
