Product Description
Product Overview
The Yokogawa NFAF135-S50 S1 is a Frequency Input Module designed to compute frequency by analyzing the number of rising edges and pulse intervals from external pulse inputs. It processes these signals and transmits the resulting process values to the CPU module via the communication bus in the base module, making it a key component for frequency-based monitoring in industrial systems.
Technical Specifications
The NFAF135-S50 S1 Frequency Input Module has the following specifications:
| Item | Specification |
|---|---|
| Model | NFAF135 |
| Number of Input Points | 8 points, individually isolated |
| Input Frequency Range | 0.1 to 10 kHz |
| Output Frequency Accuracy | 0.1% of reading |
| Output Update Cycle | 10 ms |
| Input Signals | Voltage pulse input Open-collector contact input Relay contact input |
Model and Suffix Codes
The NFAF135-S50 S1 includes the following configuration details (based on provided model number and typical Yokogawa conventions):
| Category | Details |
|---|---|
| Model | NFAF135 Frequency Input Module |
| Suffix Codes |
|
