Product Description
Optimized for Industrial Fieldbus Networks
The ALF111-S50 provides fast and reliable communication for Foundation Fieldbus (H1) devices. It functions as a Link Active Scheduler (LAS), ensuring seamless data exchange.
Fast & Stable Data Transmission
-
4 ports, supporting 1 segment per port
-
Transmission speed: 31.25 kbps for smooth communication
-
Withstanding voltage: 1500V AC (field to system)
Flexible and Scalable Connectivity
-
Supports up to 32 fieldbus devices per segment
-
Max 48 control I/O points per segment
-
Dual-redundancy support for continuous operation
-
Clock master function enhances synchronization
Designed for Easy Integration
-
Compatible with ANB10, ANB11, AFV30, AFV40, A2FV50, A2FV70
-
Pressure clamp terminals with removable blocks simplify installation
-
Dedicated cable connection to the terminal board
Power Efficiency & Safety
-
Low power consumption: 0.5A or less
-
1500V AC isolation between system and channels
-
Lightweight (0.40 kg) for easy handling
-
Basic type with no explosion protection
