Product Description
Product Overview
The Woodward 9905-760 is a Digital Synchronizer and Load Control (DSLC) Module designed for synchronizing and managing three-phase AC generators in industrial power systems. Part of Woodward’s 9900 series, this microprocessor-based unit ensures precise generator synchronization with the grid or other generators by matching frequency and phase angle, while also regulating load distribution. It is widely used in applications such as power generation, oil & gas, and marine systems, offering robust control for stable voltage and frequency management.
Technical Specifications
The 9905-760 has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | 9905-760 |
| Manufacturer | Woodward |
| Description | Digital Synchronizer and Load Control (DSLC) Module |
| Series | 9900 Series (DSLC) |
| Input Voltage | 24 VDC (18-32 VDC range) |
| Generator Voltage | 120/240 VAC (via PT input) |
| Power Consumption | 5 VA |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Weight | 0.04 kg (0.08 lbs) |
Additional Details
The 9905-760 includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Synchronizes generators and regulates load distribution |
| Mounting | Panel-mounted |
| Compatibility | Woodward speed controls, automatic voltage regulators |
| Features | Phase matching, slip frequency sync, load sharing, microprocessor-based control |
| Certifications | CE, UL |
| Part Type | New, surplus, or refurbished |
