Product Description
Product Overview
The Woodward 5417-028 is a Low-Density Analog/Discrete I/O Module designed for use within the Woodward MicroNet digital control system, which is commonly employed in turbine and engine control applications. This module provides a combination of analog and discrete input/output channels to interface with field devices such as sensors, actuators, and switches. It is typically used in industrial settings requiring precise control and monitoring, such as gas and steam turbine systems, supporting robust integration into distributed control architectures.
Technical Specifications
The 5417-028 has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | 5417-028 |
| Manufacturer | Woodward |
| Description | Low-Density Analog/Discrete I/O Module |
| Series | MicroNet |
| Analog Inputs | 8 channels, 4-20 mA or 0-5 VDC |
| Discrete Inputs | 16 channels, 24 VDC |
| Discrete Outputs | 8 channels, 24 VDC, 0.5 A |
| Power Supply | 24 VDC (via MicroNet backplane) |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Weight | 0.6 kg (1.3 lbs) |
Additional Details
The 5417-028 includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Interfaces analog and discrete signals with MicroNet control system |
| Mounting | Plugs into MicroNet chassis |
| Compatibility | MicroNet CPU modules (e.g., 5466-xxx series), turbine control systems |
| Features | High reliability, fault diagnostics, hot-swappable |
| Certifications | Meets industrial standards (e.g., CE, UL) |
| Part Type | New, surplus, or refurbished |
