Product Description
Product Overview
|
Category |
Details |
|---|---|
|
Manufacturer |
Triconex (Schneider Electric) |
|
Model/Part Number |
9674-810 |
|
Description |
Digital Output Termination Panel designed for Triconex Safety Instrumented Systems. Connects digital output modules to field devices in safety-critical environments. |
Key Features
-
10-position termination panel
-
Supports multiple Triconex digital output modules (e.g., 3604E, 3625)
-
Simplifies field wiring and installation
-
Rugged industrial design suited for harsh environments
-
Fully compatible with Tricon systems
-
Standardized terminal interface reduces wiring errors and simplifies maintenance
Technical Specifications
|
Specification |
Details |
|---|---|
|
Model |
9674-810 |
|
Product Type |
Digital Output Termination Panel |
|
Series |
Tricon |
|
Number of Positions |
10 |
|
Operating Temperature |
0°C to 60°C (32°F to 140°F) |
|
Weight |
Approx. 0.5–1.0 kg (1.1–2.2 lbs) |
|
Supported Modules |
Digital Output Modules (e.g., 3604E, 3625) |
External Connection Options
|
Connection Type |
Details |
|---|---|
|
Supported Connections |
Terminal blocks for field device wiring; system cable interface to Triconex DO modules |
Functional Features
|
Feature |
Details |
|---|---|
|
Wiring Interface |
Simplifies connection between output modules and field devices (e.g., actuators, valves) |
|
Compatibility |
Interfaces with various Triconex DO modules for system flexibility |
|
Reliability |
Rugged design supports stable operation in industrial environments |
|
Installation |
Standard terminal layout ensures fast and error-free maintenance |
Model and Configuration
|
Category |
Details |
|---|---|
|
Base Model |
9674-810 |
|
Configuration |
Standard type for digital output termination |
