Triconex 9562 3000520-390 Digital Output Termination Panel
Product Overview
- The Triconex 9562 3000520-390 is a Digital Output Termination Panel designed for Triconex safety instrumented systems (SIS) by Schneider Electric. Belonging to the Triconex Other Modules series, this panel interfaces digital output modules with field devices, ensuring reliable signal transmission in triple modular redundant (TMR) architectures. It is critical for safety applications in industries such as oil and gas, chemical, and power generation, facilitating secure and fault-tolerant control.
Technical Specifications
- The 9562 3000520-390 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 9562 3000520-390 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | Digital Output Termination Panel |
| Series | Triconex Other Modules |
| Signal Type | Digital Output, 24 VDC |
| Channel Capacity | 16 points |
| Connector Type | Terminal blocks for field wiring, multi-pin connector for I/O module |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Weight | Approx. 1.5 kg |
Additional Details
- The 9562 3000520-390 includes the following additional information based on its standard use and documentation:
- Function: Connects Triconex digital output modules (e.g., 7400206-100) to field devices like actuators or valves, transmitting control signals for safety-critical operations in TMR systems.
- Compatibility: Compatible with Triconex Tricon and Tricon CX systems; typically used with digital output modules and cables like 4000094-310 or 9101-010F for field wiring.
- Configuration: Features terminal blocks for secure field wiring and a multi-pin connector for reliable connection to I/O modules; supports TMR architecture for fault-tolerant operation.
- Certifications: Meets CE, UL, and IEC 61508 standards for Safety Integrity Level 3 (SIL3) applications; certified for use in hazardous environments.
