Triconex 7400206-100 Digital Output Module
Product Overview
- The Triconex 7400206-100 is a Digital Output Module designed for Triconex safety instrumented systems (SIS) by Schneider Electric. Belonging to the Triconex Other Modules series, this module provides reliable digital output signals for controlling field devices in safety-critical applications within triple modular redundant (TMR) architectures. It is used in industries such as oil and gas, chemical, and power generation to ensure safe and continuous operation.
Technical Specifications
- The 7400206-100 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 7400206-100 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | Digital Output Module |
| Series | Triconex Other Modules |
| Output Type | Digital, 24 VDC |
| Channel Capacity | 32 points |
| Output Current | 0.5 A per point (max) |
| Connector Type | Terminal blocks via external termination panel |
| Operating Temperature | -20°C to 70°C (-4°F to 158°F) |
| Dimensions | Approx. 150 x 120 x 50 mm |
| Weight | Approx. 0.5 kg |
Additional Details
- The 7400206-100 includes the following additional information based on its standard use and documentation:
- Function: Delivers digital output signals to control actuators, valves, or other field devices in safety-critical applications, supporting TMR fault tolerance with voting logic for high reliability.
- Compatibility: Compatible with Triconex Tricon and Tricon CX systems; interfaces with external termination panels (e.g., 9668-110) and cables like 4000094-310 for field wiring.
- Configuration: Triple modular redundant (TMR) design ensures fault tolerance; supports online module replacement without process disruption; integrates with TriStation software for configuration and diagnostics.
- Certifications: Meets CE, UL, and IEC 61508 standards for Safety Integrity Level 3 (SIL3) applications.
