Triconex 2652/1/1 Digital Output Module
Product Overview
- The Triconex 2652/1/1 is a Digital Output Module designed for the Triconex Safety Instrumented System (SIS), part of Schneider Electric’s EcoStruxure Tricon platform. It provides reliable control of digital actuators in safety-critical applications, supporting the Triple Modular Redundant (TMR) architecture to ensure fault tolerance and high availability. Used in industries like oil and gas, chemical, and power generation, the 2652-1 meets Safety Integrity Level 3 (SIL3) requirements. The external terminator assembly for this module is part number 7400166-390.
Technical Specifications
- The 2652-1 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | 2652/1/1 |
| Manufacturer | Triconex (Schneider Electric) |
| Description | Digital Output Module, 24V DC |
| Series | Tricon Safety System |
| Output Channels | 32 isolated output channels |
| Output Type | 24V DC, supervised |
| Voltage Range | 18-30V DC |
| Current Rating | 0.5 A per channel, 10 A surge for 10 ms |
| External Terminator | 7400166-390 |
| Output Rate | Up to 100 kHz |
| Power Consumption | Approx. 10 W |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Humidity | 5% to 95% non-condensing |
| Weight | Approx. 1 kg |
Additional Details
- The 2652/1/1 includes the following additional information based on its standard use and documentation:
- Function: Converts digital signals from the Triconex SIS into outputs to control actuators like valves, motors, and solenoids in applications such as emergency shutdown (ESD), fire protection, and process control. Ensures fault-tolerant operation via TMR architecture.
- Mounting: Installs in Tricon chassis (e.g., 8110, 8400) slots, interfacing with the system backplane; requires external terminator assembly (7400166-390) for field connections.
- Compatibility: Compatible with Tricon v9.6 and later systems; integrates with TriStation 1131 software for configuration and diagnostics. Works with other Tricon modules like 3008 and 4119A.
- Configuration: Configurable via TriStation 1131 software; supports hot-swappable modules for maintenance without process interruption. Features channel-to-channel isolation to prevent noise interference.
- Certifications: Meets IEC 61508 SIL3, UL, CE, and Factory Mutual (FM) standards for Class I, Division 2 hazardous locations; complies with IEC 61131 environmental and EMC requirements.
