Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Model/Part Number | 2201 |
| Description | Communication Module (CM) for Triconex Trident safety systems, designed to facilitate communication between the Trident controller and external systems or devices |
| Key Features | Supports Modbus and proprietary protocols, triple modular redundancy (TMR), multiple serial and network ports, hot-swappable, high reliability, SIL 3 certified |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 2201 |
| Product Type | Communication Module (CM) |
| Series | Trident Safety System |
| Communication Ports | 4 serial ports, 2 network ports (Ethernet) |
| Protocols | Modbus, TriStation, proprietary protocols |
| Data Rate | Up to 460.8 kbps (serial), 10/100 Mbps (Ethernet) |
| Power Supply | 24 VDC (via chassis backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Dimensions | Approx. 300 x 50 x 200 mm (11.8 x 2.0 x 7.9 in) |
| Weight | Approx. 1 kg (2.2 lbs) |
| Certifications | SIL 3 (IEC 61508), CE |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Serial (RS-232/RS-485), Ethernet (RJ45), integrates with Trident chassis backplane |
Functional Features
| Feature | Details |
|---|---|
| Communication | Enables data exchange with TriStation, Modbus devices, and external hosts |
| Redundancy | Supports TMR architecture for fault-tolerant operation |
| Hot-Swappable | Allows module replacement without system shutdown |
| Diagnostics | Built-in diagnostics for communication status and module health |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 2201 |
| Configuration | Standard, non-redundant module, configurable via TriStation software |
