Product Description
Product Overview
| Category | Details |
|---|---|
| Manufacturer | Triconex (Schneider Electric) |
| Model/Part Number | 2101 |
| Description | Remote Extender Module (RXM) for Triconex safety systems, designed to extend communication between the main Tricon chassis and remote I/O chassis over fiber optic or copper links |
| Key Features | Supports remote I/O connectivity, triple modular redundancy (TMR), fiber optic or copper communication, high reliability, SIL 3 certified, hot-swappable |
Technical Specifications
| Specification | Details |
|---|---|
| Model | 2101 |
| Product Type | Remote Extender Module (RXM) |
| Series | Tricon Safety System |
| Communication Interface | Fiber optic or copper |
| Distance | Up to 2 km (fiber optic) or 100 m (copper) |
| Data Rate | Up to 1 Mbps |
| Power Supply | 24 VDC (via chassis backplane) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Dimensions | Approx. 300 x 50 x 200 mm (11.8 x 2.0 x 7.9 in) |
| Weight | Approx. 1 kg (2.2 lbs) |
| Certifications | SIL 3 (IEC 61508), CE |
External Connection Options
| Connection Type | Details |
|---|---|
| Supported Connections | Fiber optic (SC/ST connectors) or copper (RJ45), connects to Tricon main and remote chassis |
Functional Features
| Feature | Details |
|---|---|
| Remote Connectivity | Extends communication to remote I/O chassis for distributed safety systems |
| Redundancy | Supports TMR architecture for fault-tolerant operation |
| Hot-Swappable | Allows module replacement without system shutdown |
| Diagnostics | Built-in diagnostics for link status and module health |
Model and Configuration
| Category | Details |
|---|---|
| Base Model | 2101 |
| Configuration | Standard, supports fiber optic or copper links, non-redundant module |
