Siemens 6SL3300-1AE32-5AA0 Data sheet for Braking Module

Siemens 6SL3300-1AE32-5AA0 Data sheet for Braking Module

  • Manufacturer: Siemens

  • Product No.: 6SL3300-1AE32-5AA0

  • Condition:1000 in stock

  • Product Type: Data sheet for Braking Module

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 7300g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Details

Manufacturer: SIEMENSModel/Part Number: 6SL3300-1AE32-5AA0Description: Data sheet for Braking Module

Rated Data:

  • Rated power PDB: 50.00 kW

  • Rated power, max.: 250.00 kW

  • Activation threshold: 774 V (673 V), adjustable via DIP switch

General Technical Specifications:

  • DC link voltage: DC 510 ... 720 V

Mechanical Data:

  • Net weight: 7.3 kg (16.09 lb)

Digital Inputs:

  • Number: 1

  • Voltage: 24 V

  • Low level: -3 V ... 5 V

  • High level: 15 V ... 30 V

  • Power consumption at 24 V DC, typ.: 10 mA

Digital Outputs:

  • Number: 1

  • Voltage: DC 24 V

  • Load current per digital output, max.: 500 mA

Connections:

Feature Value
Digital inputs Connection cross-section, max. 1.5 mm² (16 AWG)
Digital outputs Connection cross-section, max. 1.5 mm² (16 AWG)
PE connection Version on housing M8 nut
BrakeResistor Connection cross-section, max. 50.0 mm² (1 AWG)



View full details

Product Description

Product Details

Manufacturer: SIEMENSModel/Part Number: 6SL3300-1AE32-5AA0Description: Data sheet for Braking Module

Rated Data:

  • Rated power PDB: 50.00 kW

  • Rated power, max.: 250.00 kW

  • Activation threshold: 774 V (673 V), adjustable via DIP switch

General Technical Specifications:

  • DC link voltage: DC 510 ... 720 V

Mechanical Data:

  • Net weight: 7.3 kg (16.09 lb)

Digital Inputs:

  • Number: 1

  • Voltage: 24 V

  • Low level: -3 V ... 5 V

  • High level: 15 V ... 30 V

  • Power consumption at 24 V DC, typ.: 10 mA

Digital Outputs:

  • Number: 1

  • Voltage: DC 24 V

  • Load current per digital output, max.: 500 mA

Connections:

Feature Value
Digital inputs Connection cross-section, max. 1.5 mm² (16 AWG)
Digital outputs Connection cross-section, max. 1.5 mm² (16 AWG)
PE connection Version on housing M8 nut
BrakeResistor Connection cross-section, max. 50.0 mm² (1 AWG)



Download PDF file here:

Click to Download PDF
