Schneider Electric BMXXBP1200 Backplane

Schneider Electric BMXXBP1200 Backplane

  • Manufacturer: Schneider Electric

  • Product No.: BMXXBP1200

  • Condition:1000 in stock

  • Product Type: Backplane

  • Product Origin: FRANCE

  • Payment: T/T, Western Union

  • Weight: 1270g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Information: Schneider Backplane - BMXXBP1200

Manufacturer:

  • Schneider Electric

Model/Part Number:

  • BMXXBP1200 (Backplane)

Description:

The BMXXBP1200 is a backplane designed for use with the Modicon X80 automation system. It features 12 bus slots, providing expanded capacity for integration with various modules including BMXP34 processors, BMXCPS power supplies, I/O modules, and specific application modules. With a compact design and easy installation options, this backplane is ideal for applications requiring a higher number of bus slots while maintaining low power consumption and high reliability.


Specifications:

Feature Specification
Range of Product Modicon X80
Product Type Backplane
Number of Slots 12 bus X slots
Product Compatibility BMXP34 processor, BMXCPS power supply, I/O modules, Specific application modules
Power Consumption 0.17 W
Electrical Connection 1 connector (XBE) for expansion module
Fixing Mode By 4 M4/M5/M6 screws (panel or mounting plate)
Height 103.7 mm (4.08 in)
Width 503.2 mm (19.79 in)
Depth 19 mm (0.75 in)
Net Weight 1.27 kg (2.80 lb)

Environmental Specifications:

Feature Specification
IP Protection Degree IP20
Ambient Air Temperature (Operation) 0…60 °C (32…140 °F)
Relative Humidity 10…95 % (without condensation)

Certifications and Standards:

Feature Specification
Product Certifications CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy
Compliance Directives 2014/35/EU (Low Voltage Directive), 2014/30/EU (Electromagnetic Compatibility)
Standards EN/IEC 61131-2, EN/IEC 61010-2-201, UL 61010-2-201, CSA C22.2 No 61010-2-201
IACS E10, EN/IEC 61000-6-5 (interface types 1 and 2)
EN/IEC 61850-3 (location G)

Key Features:

  • 12 Bus Slots: Provides 12 bus X slots for greater system expandability and integration of multiple modules.
  • Low Power Consumption: With only 0.17 W power consumption, this backplane is energy-efficient and ideal for various industrial environments.
  • Mounting Flexibility: Designed to be mounted using 4 M4/M5/M6 screws, either on a panel or mounting plate, providing versatile installation options.
  • Compact Design: With dimensions of 103.7 mm in height, 503.2 mm in width, and 19 mm in depth, the backplane offers a compact form factor for space-constrained setups.
  • Global Certifications: Certified to international standards like CE, UL, CSA, and IEC, ensuring safety and compliance across a wide range of applications.
  • Environmentally Robust: Operates in temperatures ranging from 0°C to 60°C and is suitable for environments with 10-95% relative humidity (without condensation).
