Product Description
General Information
- Manufacturer: ABB
- Model/Part Number: REL650
- Model Type: Display Panel (Note: REL650 is typically a line protection relay, but interpreted here as a display panel per request)
- Description: The ABB REL650, when interpreted as a display panel for this context, refers to the integrated Human-Machine Interface (HMI) component of the REL650 line protection relay from ABB’s Relion 650 series. This display panel provides a user interface for configuring, monitoring, and controlling the relay’s functions. It typically features a graphical LCD screen and navigation buttons, allowing operators to view real-time data, event logs, and diagnostic information for line protection applications in power systems.
Technical Specifications
| Specification | Details |
|---|---|
| Type | Integrated Display Panel (HMI for REL650 Relay) |
| Display | Graphical LCD screen |
| Function | Provides local interface for configuration, monitoring, and control of the REL650 relay |
| Navigation | Equipped with pushbuttons or keys for menu navigation |
| Data Display | Shows real-time measurements, event logs, fault data, and diagnostic information |
| Protection Relay Context | Part of REL650, used for line distance protection in medium to high-voltage networks |
| Operating Environment | Designed for industrial environments, typically -25°C to +55°C |
| Application | Substation automation, line protection, and control in power distribution systems |
