Product Description
Product Overview
The PVTVM TM0180-07-00-07-05-02 is a Proximity Probe Vibration Sensor designed for non-contact vibration monitoring of rotating machinery, such as turbines, pumps, and compressors. Manufactured by PVTVM (also branded as ProvibTech), a specialist in condition monitoring solutions, this sensor employs eddy current technology to measure shaft vibration and displacement, delivering critical data for predictive maintenance and equipment protection. It is widely used in industrial applications, including power generation, oil and gas, and manufacturing, where it integrates with monitoring systems via an extension cable (e.g., TM0181) and a driver (e.g., TM0182). The TM0180-07-00-07-05-02 features a rugged, API 670-compliant design with a standard protective rubber boot, ensuring reliable performance in harsh environments and compatibility with standard vibration analysis setups.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | PVTVM (ProvibTech) |
| Series | TM0180 |
| Model/Part Number | TM0180-07-00-07-05-02 |
| Description | Proximity Probe Vibration Sensor |
| Probe Diameter | 8 mm |
| Measurement | Shaft vibration and displacement |
| Linear Range | 2 mm (80 mils), 0.25 mm to 2.25 mm (10 to 90 mils) |
| Unthreaded Length | 0 mm (0 in) |
| Case Length | 70 mm (2.76 in) |
| Total Length | 5 meters (16.4 ft) |
| Power Supply | -23 to -30 Vdc (via driver/monitor) |
| Operating Temperature | -40 °C to +177 °C (-40 °F to +350 °F) |
| Dimensions | 70 mm L x 8 mm Dia (2.76 in x 0.31 in, probe tip); 5 m cable |
| Weight | 0.25 kg (0.55 lb) |
