Product Description
Product Overview
The PREDICTECH TM0180-07-00-04-05-02 is a Proximity Probe Vibration Sensor designed for non-contact vibration monitoring of rotating machinery, such as turbines, compressors, and pumps. Manufactured by PredicTech (also branded as ProvibTech), a leader in condition monitoring solutions, this sensor uses eddy current technology to measure shaft vibration and displacement, providing essential data for predictive maintenance and equipment protection. It is widely deployed in industrial applications, including power generation, oil and gas, and manufacturing, where it integrates with monitoring systems via an extension cable (e.g., TM0181) and a driver (e.g., TM0182). The TM0180-07-00-04-05-02 features a rugged, API 670-compliant design, ensuring reliable performance in harsh environments and compatibility with standard vibration analysis systems.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | PREDICTECH (ProvibTech) |
| Series | TM0180 |
| Model/Part Number | TM0180-07-00-04-05-02 |
| Description | Proximity Probe Vibration Sensor |
| Probe Diameter | 8 mm |
| Measurement | Shaft vibration and displacement |
| Linear Range | 2 mm (80 mils) |
| Unthreaded Length | 0 mm (0 in) |
| Case Length | 40 mm (1.57 in) |
| Total Length | 5 meters (16.4 ft) |
| Power Supply | -23 to -30 Vdc (via driver/monitor) |
| Operating Temperature | -40 °C to +177 °C (-40 °F to +350 °F) |
| Dimensions | 40 mm L x 8 mm Dia (1.57 in x 0.31 in, probe tip); 5 m cable |
| Weight | 0.22 kg (0.49 lb) |
