Product Description
Product Details
Manufacturer: BACHMANN
Model/Part Number: MC205
Description: Processor Module
Specifications
| Category | Details |
|---|---|
| CPU |
600 MHz ATOM E620
|
| I/O Bus | Process image controller |
| CFast (Mass Storage) | 1x integrated (accessible from the side) / >8 GB |
| RAM | 1 GB DRAM DDR2 |
| nvRAM-0 (Data Memory) | 512 kB |
| Internal FLASH | 64 MB (40 MB free for application programs) |
Interfaces
- Serial: 1x RS232 + 1x RS232/422/485 (software configurable)
- Ethernet: 2x 10/100/1000 Base-T with IEEE1588
- USB Host: 1x USB 2.0
- Service USB Interface: 1x USB device
Additional Features
- Watchdog
- Synchronizing pulse also for I/O bus, fieldbuses SERCOS and CAN, Ethernet
- Real-time clock with battery
- Status indication via 3 LEDs
- CPU ID selectable with rotary hexadecimal switches
- Operating System: VxWorks with Bachmann system extensions on internal FLASH
Environmental Conditions
- Operating Temperature: -30°C to +60°C, fan-free
- Storage Temperature: -40°C to +85°C
- Relative Humidity (Operation): 5–95% without condensation / 5–95% with condensation
- Relative Humidity (Storage): 5–95% without condensation / 5–95% with condensation
Design Variants
- Processor: ATOM E620 (600MHz)
- Memory: 1 GB DRAM, 512 kB nvRAM, 64 MB file-flash
- Interfaces: 2x Eth100/1000, 1x RS232, 1x RS232/422/485, 1x USB 2.0 (host), 1x USB 2.0 (device)
- Storage: CFast slot
