Product Description
General Information
- Manufacturer: ICS Triplex (Rockwell Automation)
- Model/Part Number: T8442
- Description: The ICS Triplex T8442 is a Trusted TMR Speed Monitor Module from the Trusted Triple Modular Redundant (TMR) System. This module is designed to provide high-integrity speed monitoring for rotating machinery, interfacing with up to three speed sensors to deliver fault-tolerant, fail-safe operation. It is used in safety-critical applications within industrial automation, such as turbine overspeed protection, ensuring precise and reliable speed data in environments like power generation and oil and gas.
Technical Specifications
| Specification | Details |
|---|---|
| Type | Trusted TMR Speed Monitor Module |
| Series | Trusted TMR System |
| Inputs | 3 speed sensor inputs (active or passive) |
| Input Voltage Range | 18 to 32 V DC (Group Vfield) |
| Maximum Input Current | 1 A (Group Vfield) |
| Speed Range | Configurable, typically up to 60,000 RPM |
| Outputs | Speed data via Inter-Module Bus (IMB) |
| Operating Temperature | 0°C to +60°C (32°F to +140°F) |
| Weight | Approximately 1.2 kg (2.65 lbs) |
| Application | Industrial automation, machinery protection, overspeed monitoring |
