| Number of Communication Ports |
Two (2) Genius terminals |
| Bulletin |
IC200 |
| Redundancy |
Supported |
| Product Type |
Network Interface Unit |
| Number of Modules |
Eight (8) modules |
| Network Inputs/Bus Scan |
128 bytes |
| Number of Racks |
Eight (8) racks |
| I/O Memory |
1024 points |
| Supported Transmission Rate |
153.6 kbaud (extended network configuration); 153.6 kbaud, 76.8 kbaud, 38.4 kbaud (standard) |
| Analog I/O Memory |
128 bytes |
| Wiring Topology |
Daisy-chain |
| Power Rating at 250 mA |
5 V |
| Terminating Resistor |
75, 100, 120, or 150 ohms |
| Power Rating at 10 mA |
3.3 V |
| Compatible Controllers |
Series 90-70; PACSystem RX7i; PACSystem RX3i |
| Serial Bus Address Range |
0 to 31 |
| Number of Discrete I/O |
2048 |
| Number of I/O |
64 |
| Number of Discrete Inputs |
1024 |
| Number of Discrete Outputs |
1024 |
