Honeywell MTL4544 CC-GAIX21 Analog Input

Honeywell MTL4544 CC-GAIX21 Analog Input

  • Manufacturer: HONEYWELL

  • Product No.: CC-GAIX21

  • Condition:1000 in stock

  • Product Type: Analog Input

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 1000g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

Manufacturer: Honeywell
Model/Part Number: CC-GAIX21
Description: Analog Input

The Honeywell CC-GAIX21 is an Analog Input IOTA that accommodates up to sixteen high-level DC signals. This IOTA does not support redundancy and provides galvanically isolated inputs when used with the MTL4544 (two-channel) isolator.


Supported Isolators for CC-GAIX21

Item MTL4544 (CC-GAIX21)
Maximum Current Consumption (with 20mA signal) 95mA at 24V
Maximum Power Dissipation (with 20mA signal) 1.4W at 24V
Isolation 250V AC (hazardous area to safe/power supply circuits) 100V AC (safe to power supply circuits)
Temperature Drift <0.8μA/°C
Safety Description Terminals 2 to 1 and 3, and 5 to 4 and 6: Vo=28V, Io=93mA, Po=651mW, Um=253V rms/dc Terminals 1 to 3 and 4 to 6: Non-energy-storing apparatus (≤1.2V, ≤0.1A, ≤20μJ, ≤25mW); can be connected without further certification into any IS loop with an open-circuit voltage <28V
Configuration Socket Vo=7.2V, Io=14.5mA, Po=26mW
View full details

Product Description

Product Overview

Manufacturer: Honeywell
Model/Part Number: CC-GAIX21
Description: Analog Input

The Honeywell CC-GAIX21 is an Analog Input IOTA that accommodates up to sixteen high-level DC signals. This IOTA does not support redundancy and provides galvanically isolated inputs when used with the MTL4544 (two-channel) isolator.


Supported Isolators for CC-GAIX21

Item MTL4544 (CC-GAIX21)
Maximum Current Consumption (with 20mA signal) 95mA at 24V
Maximum Power Dissipation (with 20mA signal) 1.4W at 24V
Isolation 250V AC (hazardous area to safe/power supply circuits) 100V AC (safe to power supply circuits)
Temperature Drift <0.8μA/°C
Safety Description Terminals 2 to 1 and 3, and 5 to 4 and 6: Vo=28V, Io=93mA, Po=651mW, Um=253V rms/dc Terminals 1 to 3 and 4 to 6: Non-energy-storing apparatus (≤1.2V, ≤0.1A, ≤20μJ, ≤25mW); can be connected without further certification into any IS loop with an open-circuit voltage <28V
Configuration Socket Vo=7.2V, Io=14.5mA, Po=26mW

Download PDF file here:

Click to Download PDF
