Product Description
Product Overview
Manufacturer: Honeywell
Model/Part Number: FS-PSU-240516
Description: Control Processor Modules
Technical Data
General Specifications
- Type Numbers: FS-PSU-240516, FC-PSU-240516
- Operating Temperature: -5°C to +70°C (+23°F to +158°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Relative Humidity: 10% to 95% (non-condensing)
- Approvals: CE, TUV, UL, CSA, FM
Power Specifications
| Parameter | Value |
|---|---|
| 24 V Supply Voltage | 24 V DC (-15% to +30%) |
| 24 V Supply Current | < 6 A at 24 Vin (16 A load) < 7 A at 20.4 Vin (16 A load) |
| Inrush Current | < 5 A at 24 Vin |
| 5V Load | Min. 0.5 A, Max. 16 A |
| 5VR Load | Min. 0.5 A, Max. 16 A |
| Hold-up Time | < 1 ms |
Physical Specifications
- Dimensions (H × W × D): 176 × 35.2 × 212 mm (6.93 × 1.4 × 8.35 in)
- Weight: 0.85 kg
