Product Description
General Information
|
Manufacturer |
Honeywell |
|---|---|
|
Model/Part Number |
FC-BKM-0001 |
|
Description |
Control Processor Module |
|
Approvals |
CE, TUV, UL, CSA, FM |
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Operating Temperature |
-5°C to +70°C (+23°F to +158°F) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Relative Humidity |
10-95% (non-condensing) |
Power Specifications
|
Parameter |
Specification |
|---|---|
|
24 V Supply Voltage |
24 V DC ±15%-+30% |
|
24 V Supply Current |
Max. 20 mA (out of each 24 V DC) typ. 7 mA (shared load on 24 V DC) |
|
5 VR Supply Voltage |
5 V DC ±10% |
|
5 VR Supply Current |
Max. 10 mA |
|
+24V_red Output Supply Voltage |
14-31 V DC |
|
Output Resistance |
Approx. 2 × 1.1 kΩ (parallel) |
|
Short Circuit Protection |
Continuous |
Battery Specifications
|
Parameter |
Specification |
|---|---|
|
Battery Make |
SAFT |
|
Battery Type |
LS14500CFG |
|
Material |
Lithium Thionyl Chloride |
|
Nominal Voltage |
3.6 V |
|
Capacity |
> 2 Ah |
|
Size |
AA |
|
Operating Temperature |
-40°C to +85°C (-40°F to +185°F) |
Physical Specifications
|
Parameter |
Specification |
|---|---|
|
Dimensions (H × W × D) |
176 × 35.2 × 224 mm (6.93 × 1.4 × 8.81 in) |
|
Weight |
660 g |
