Product Description
Honeywell DC-TAID01 Analog Input Module
Product Overview
- The Honeywell DC-TAID01 is an Analog Input Module designed for use in Honeywell’s TDC 3000 and Experion Process Knowledge System (PKS) platforms. This module facilitates precise analog signal acquisition from field devices, enabling seamless integration into industrial control systems for applications such as process monitoring and automation.
Technical Specifications
- The DC-TAID01 has the following specifications based on standard characteristics for this model:
| Specification | Details |
|---|---|
| Model/Part Number | DC-TAID01 |
| Manufacturer | Honeywell |
| Description | Analog Input Module |
| Series | TDC 3000 / Experion PKS |
| Input Channels | 16 channels, differential |
| Input Range | -10 V to +10 V or 4 to 20 mA |
| Accuracy | ±0.1% FS ±1 Digit |
| Response Time | ≤10 ms |
| Power Supply | 24 VDC nominal (via I/O rack) |
| Power Consumption | ≤2 W |
| Operating Temperature | -40°C to +85°C (-40°F to +185°F) |
| Weight | Approx. 0.3 kg |
Additional Details
- The DC-TAID01 includes the following additional information based on its standard use and documentation:
- Function: Processes analog input signals from sensors and field devices for real-time monitoring and control.
- Mounting: Installs in TDC 3000 or Experion I/O rack, typically with an Input/Output Termination Assembly (IOTA).
- Compatibility: TDC 3000 Process Manager, Experion C300 Controller, and related I/O modules.
- Configuration: Configurable via Honeywell’s control system software for specific input types and ranges.
- Certifications: Meets UL, CE, and ATEX standards for industrial environments.
