Product Description
Product Overview
The Honeywell CC-TAIX11 is an Analog Input IOTA (Input/Output Termination Assembly) Redundant Board designed for use within Honeywell’s Experion Process Knowledge System (PKS), specifically the Series C architecture. Manufactured by Honeywell, a leader in automation solutions, this board supports 16 differential analog input channels for high-level current (e.g., 4-20 mA) or voltage signals from transmitters and sensors. It is suited for industrial applications in oil and gas, chemical processing, and power generation, featuring extensive self-diagnostics, optional redundancy, and non-incendive field power supply capabilities. The CC-TAIX11 integrates with Series C Analog Input Modules (e.g., CC-PAIX01), providing a robust termination point for field wiring in distributed control system (DCS) environments.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | Honeywell |
| Series | Experion PKS (Series C) |
| Model/Part Number | CC-TAIX11 |
| Associated Part Number | 51308365-175 |
| Description | Analog Input IOTA Redundant Board, 16 Channels |
| Number of Channels | 16 (differential inputs) |
| Input Type | High-level analog (4-20 mA, voltage configurable) |
| Power Consumption | 0.195 A at 24 V DC |
| Compatibility | Series C Analog Input Module (e.g., CC-PAIX01) |
| Operating Temperature | 0 °C to +60 °C (32 °F to +140 °F) |
| Dimensions | 305 mm L x 152 mm W x 25 mm H (12 in x 6 in x 1 in) |
| Weight | 0.45 kg (1 lb) |
