Product Description
Product Overview
The Honeywell CC-SDRX01 is a Digital Input Module designed for the Experion Process Knowledge System (PKS) Series 8 I/O platform. It provides 32 channels of digital input, interfacing with field devices such as switches, sensors, and other on/off equipment in industrial automation applications. This module is engineered for high reliability and seamless integration with Honeywell’s distributed control systems (DCS), supporting process control in demanding environments.
Technical Specifications
The CC-SDRX01 has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | CC-SDRX01 |
| Manufacturer | Honeywell |
| Description | Digital Input Module |
| Series | Experion Series 8 I/O |
| Input Channels | 32 digital inputs |
| Input Voltage | 24 VDC nominal |
| Input Range | 18-30 VDC |
| Input Current | 6 mA per channel at 24 VDC |
| Power Supply | 24 VDC (via Series 8 IOTA) |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Weight | 0.3 kg |
Additional Details
The CC-SDRX01 includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Receives and processes 32 digital input signals from field devices |
| Mounting | Attaches to Series 8 Input Output Termination Assembly (IOTA) |
| Compatibility | Experion PKS C300 Controller and Series 8 I/O systems |
| Indicators | Status monitored via Experion system diagnostics |
| Certifications | Meets UL, CE, and ATEX standards for industrial use |
| Part Type | New, surplus, or refurbished (depending on supplier) |
