Product Description
General Information
|
Manufacturer |
Honeywell |
|---|---|
|
Model/Part Number |
CC-PUIO31 |
|
Description |
Universal Input Output |
Function
The Universal Input Output module interfaces with analog input, analog output, digital input, and digital output field devices.
Notable Features
• Channel Configuration Options:
• Analog Input
• Analog Output
• Digital Input
• DISOE (Sequence of Events) with 1ms resolution for SOE and 20ms PV scan
• Digital Output
• Pulse Input (available on any four channels)
• Additional Features:
• Open Wire Detection
• Electronic Short Circuit Protection
• Fast Scan (Priority I/O Module Scan)
• Safe-state (FAILOPT) behaviors configurable for Digital / Analog Output
• HART 7 Support (for Analog I/O)
• HART Modem per Channel for Fast Performance
• Extended Temperature Range: -40°C to +70°C (ambient module temperature)
Model Specifications
|
Parameter |
Specification |
|---|---|
|
Universal Process IO Module |
CC-PUIO31 |
|
IOTA Model Numbers |
CC-TUIO31 (Non Redundant, 9”), CC-TUIO41 (Redundant, 12”) |
