Product Description
Product Overview
The Honeywell CC-PCNT02 51454551-275 C300 Controller Module is a high-performance control unit within Honeywell’s Experion Process Knowledge System (PKS). Designed for industrial process control, this module supports advanced control execution environments (CEE) and integrates with both Series C and legacy I/O systems. Offering dual-redundant configurations, multiple I/O link speeds, and support for modern time synchronization protocols like SNTP and PTPv2, it provides a flexible and robust solution for managing complex automation tasks.
Technical Information
| Item | 50 ms CEE | 20 ms CEE |
|---|---|---|
| Manufacturer | Honeywell | |
| Model/Part Number | CC-PCNT02 51454551-275 | |
| Description | C300 Controller Module | |
| Control Networks Supported | FTE only | FTE only |
| Supported C300 Models | CC-PCNT01, CC-PCNT02 | CC-PCNT01, CC-PCNT02 |
| Device Index Configuration | Between 1 and 510 | Between 1 and 510 |
| IOTA Size | 6 inches | 6 inches |
| Number of I/O Links Supported | 2 | 2 |
| I/O Link Speeds Available | 375 Kbaud (PMIO Link) 750 Kbaud (Series C IO Link) |
750 Kbaud (Series C IO Link) 375 Kbaud (PMIO Link) not supported |
| Base Execution Periods Supported | 50 ms | 20 ms (optional, requires firmware and license) (*4) |
| Redundancy Supported | Yes | Yes |
| Remote – Non-Series C I/O Supported | Yes – PM I/O or Series A I/O (*3) | No – Only Series C I/O supported with limited capacities |
| I/O Module Execution Period | 50 ms | 20 ms |
| Configurable Values for CM/SCM/RCM Execution Periods | 50, 100, 200, 500, 1000, 2000, 5000, 10000, 20000, 30000, 60000 ms | 20, 40, 80, 200, 400, 800 ms (CMs only – SCM/RCM/MR not supported) |
| Configurable Values of Peer Update Rates (Period) | 100, 200, 500, 1000 ms | 100, 200, 500, 1000 ms |
| C300 Time Source | SNTP, PTPv2 | SNTP, PTPv2 |
| SNTP Update Period | 1 minute | 1 minute |
| GPS Time Support (*2) | No | No |
| PTP Update Period | 30 seconds | 30 seconds |
Specific Configuration
- Model/Part Number: CC-PCNT02 51454551-275
- Configuration Details:
- No suffix or option codes specified beyond model number, indicating a standard configuration
