Product Description
General Information
|
Manufacturer |
Honeywell |
|---|---|
|
Model/Part Number |
8C-PDILA1 (51454471-175) |
|
Description |
Digital Input, 24VDC, Coated |
Specifications
|
Parameter |
Specification |
|---|---|
|
Input/Output Module |
8C-PDILA1 - Digital Input 24VDC, Coated 8U-PDILA1 - Digital Input 24VDC, Uncoated |
|
IOTA Modules |
8C-TDILA1 - Non-Redundant, Coated, 9” 8U-TDILA1 - Non-Redundant, Uncoated, 9” 8C-TDILB1 - Redundant, Coated, 12” 8U-TDILB1 - Redundant, Uncoated, 12” |
|
Input Channels |
32 |
|
Galvanic Isolation (System-to-Field Isolation for user-supplied field power) |
1000 VAC RMS |
|
Isolation Technique |
Optical (In IOM) |
|
Voltage Rating |
24 VDC |
|
Module Current Rating |
95 mA |
|
DI Power Voltage Range |
18 to 30 VDC (for user-supplied field power) |
|
Module Removal and Insertion Under Power |
Supported |
|
ON Sense Voltage/Current |
13 VDC (min) or 3 mA (min) |
|
OFF Sense Voltage/Current |
5 VDC (max) or 1.2 mA (max) |
|
Input Impedance |
4.2 KΩ |
|
Absolute Delay Across Input Filter and Isolation |
5 ms ± 20% |
