Product Description
Product Overview
- The Honeywell 51402199-100 Enhanced Peripheral Display (EPD) Module is a robust graphical interface component within Honeywell’s Distributed Control System (DCS) product line, such as the TotalPlant Solution (TPS) or Experion platforms. Designed to provide operators with a clear, real-time view of industrial processes, this module supports monitoring and control tasks with features like a 32-point 24 V DC digital output, a 64-point temperature multiplexer, and digital input sequence of events (SOE) capability. With a compact size of 36.6 x 36.3 x 1.5 cm and a weight of 0.76 kg, it is NEMA 4X and IP66 rated, ensuring durability in harsh industrial environments across a wide temperature range.
Technical Information
| Parameter | Specifications |
|---|---|
| Manufacturer | Honeywell |
| Model/Part Number | 51402199-100 |
| Description | Enhanced Peripheral Display (EPD) Module |
| Dimensions (LxWxH) | 36.6 x 36.3 x 1.5 cm (14.41 x 14.29 x 0.59 in) |
| Weight | 0.76 kg (1.68 lb) |
| Digital Output | 24 V DC, 32 points |
| Temperature Multiplexer | 64 points |
| Digital Input | Sequence of Events (SOE) capability |
| Environmental Rating | NEMA 4X and IP66 (suitable for harsh environments) |
| Power Requirements | 24 V DC, 2.5 A |
| Operating Temperature | -40°C to 70°C (-40°F to 158°F) |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Humidity | 0% to 95% non-condensing |
| Vibration | 0.5 g RMS, 5 to 500 Hz |
| Shock | 15 g, 11 ms half-sine pulse |
