Product Description
Product Overview
The Honeywell 2108B2001 is a Searchpoint Optima Plus Infrared Gas Detector designed for industrial safety applications. It is a point-type hydrocarbon gas detector utilizing infrared technology to detect flammable gases in potentially explosive atmospheres. Certified for hazardous areas, this model offers fast response times and fail-safe operation, making it ideal for industries such as oil and gas, petrochemical, and chemical processing.
Technical Specifications
The 2108B2001 has the following specifications based on standard characteristics for this model:
| Item | Specification |
|---|---|
| Model/Part Number | 2108B2001 |
| Manufacturer | Honeywell |
| Description | Searchpoint Optima Plus Infrared Gas Detector |
| Series | Searchpoint Optima Plus |
| Gas Type | Hydrocarbon gases (calibrated to methane, 0-100% LEL) |
| Measurement Range | 0-100% LEL (Lower Explosive Limit) |
| Output Signal | 4-20 mA |
| Power Supply | 18-32 VDC (24 VDC nominal) |
| Power Consumption | 4.5 W maximum |
| Operating Temperature | -40°C to 65°C (-40°F to 149°F) |
| Weight | 1.6 kg (3.5 lbs) |
Additional Details
The 2108B2001 includes the following additional information based on its standard use and documentation:
| Category | Details |
|---|---|
| Function | Detects hydrocarbon gases using infrared technology |
| Certifications | ATEX, IECEx, UL, CSA (hazardous area approved) |
| Enclosure | Stainless steel, IP66/67 rated |
| Mounting | Fixed installation (wall or pipe mount) |
| Compatibility | Integrates with Honeywell controllers and PLCs |
| Maintenance | Self-diagnostic with minimal routine maintenance |
| Part Type | New, surplus, or refurbished (depending on supplier) |
