Product Description
Product Details
|
Manufacturer |
HIMA |
|---|---|
|
Model/Part Number |
K9203 |
|
Description |
Rack Fan |
Technical Specifications
|
Attribute |
Specification |
|---|---|
|
Material |
Aluminum, anodized |
|
Operating Voltage |
24 VDC (-15% to +20%), rPP ≤ 15% |
|
Current Consumption |
Max. 750 mA |
|
Air Flow |
300 m³ per hour |
|
Rated Speed |
2800 min⁻¹ |
|
Sound Pressure Level |
Approx. 55 dB(A) |
|
Lifetime (at 40°C) |
62,500 hours |
|
Space Requirement |
19’’ rack, 1 RU, depth 215 mm |
|
Weight |
1.8 kg |
|
Ambient Temperature Range |
-20 to +70 ºC |
