Product Description
Product Details
|
Manufacturer |
HIMA |
|---|---|
|
Model/Part Number |
F6217 984621702 |
|
Description |
analog input module |
Technical Specifications
Electrical Characteristics
|
Parameter |
Value |
|---|---|
|
Input Voltage |
0…5.5 V |
|
Max. Input Voltage |
7.5 V |
|
Input Current |
0…22 mA (via shunt) |
|
Max. Input Current |
30 mA |
|
Shunt |
250 Ohm; 0.05 %; 0.25 W; current input T<10 ppm/K (Part No: 00 0710251) |
|
Resolution |
12 bit (0 mV = 0, 5.5 V = 4095) |
|
Measurand Update |
50 ms |
|
Safety Time |
< 450 ms |
|
Input Resistance |
100 kOhm |
|
Time Constant of Input Filter |
Approx. 10 ms |
|
Basic Error |
0.1 % at 25 °C |
|
Operating Error |
0.3 % at 0…+60 °C |
|
Error Limit Related to Safety |
1 % |
|
Electric Strength |
200 V against GND |
Physical and Power Requirements
|
Parameter |
Value |
|---|---|
|
Space Requirement |
4 TE |
|
Operating Data |
5 V DC: 80 mA, 24 V DC: 50 mA |
