Product Description
General Information:
- Extended Product Type: 07KT98
- Product ID: GJR5253100R4278
- ABB Type Designation: 07KT98
- Catalog Description: 07KT98 Basic Module Ethernet AC31
- Country of Origin: Germany (DE)
Environmental Information:
-
Ambient Air Temperature:
- Operation: 0 … +55 °C
- Storage: -25 … +75 °C
Inputs and Outputs:
-
Analog Inputs:
- 8 channels: 0 … +5V, -5 … +5V (10 bit + sign), 0 … +10V, -10 … +10V (11 bit + sign)
- 0 … 20mA, 4 … 20mA
- PT100 (2 or 3 wire), 12 bit, bipolar
- The analog inputs are also usable as digital inputs
-
Analog Outputs:
- 4 channels: -10 … +10V (11 bit + sign)
- 0 … 20mA (12 bit)
-
CS31-Bus: 1
Dimensions and Weight:
| Feature | Measurement |
|---|---|
| Product Net Weight | 1.62 kg |
