Product Overview
The General Electric IS220PAICH1B is an Analog Input/Output Pack from the GE Mark VIe Speedtronic Series, designed to interface analog signals with turbine control systems in industrial automation. Manufactured by GE, now under Emerson Automation Solutions following the 2019 acquisition of GE Intelligent Platforms, this module serves as an electrical bridge between one or two Ethernet I/O networks and an analog input terminal board, digitizing sensor signals for precise control and monitoring. It features 10 analog inputs and 2 analog outputs, dual 100 MB Ethernet ports, and is suited for gas, steam, and wind turbine applications in power generation and process control, supporting simplex, dual, or triple modular redundant (TMR) configurations with a conformal coating for durability.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | General Electric (GE) / Emerson Automation Solutions |
| Series | Mark VIe Speedtronic |
| Model/Part Number | IS220PAICH1B |
| Description | Analog Input/Output Pack |
| Input Channels | 10 (8 configurable: ±5 V, ±10 V, or 4-20 mA; 2 configurable: ±1 mA or 4-20 mA) |
| Output Channels | 2 (0-20 mA current loop) |
| Communication Ports | 2 Ethernet (100 MB full-duplex) |
| Power Supply | 22.5-28.6 V DC (nominal 24 V DC or 28 V DC) |
| Analog Transmitter Power | 22.8 V DC |
| Operating Temperature | -40 °C to +70 °C (-40 °F to +158 °F) |
| Weight | 0.45 kg (1 lb) |
