Product Overview
The General Electric IC695ALG616 is a Non-Isolated Differential Analog Input Module from the GE Fanuc RX3i PACSystems Series, designed for high-precision analog signal acquisition in industrial automation. Manufactured by GE, now under Emerson Automation Solutions following the 2019 acquisition of GE Intelligent Platforms, this module features 16 single-ended or 8 differential input channels, supporting a wide range of voltage and current signals. It is suited for applications in manufacturing, power generation, and process control, offering robust features like autocalibration, fault detection, and compatibility with RX3i universal backplanes.
Technical Information
| Item | Specifications |
|---|---|
| Manufacturer | General Electric (GE) / Emerson Automation Solutions |
| Series | RX3i PACSystems |
| Model/Part Number | IC695ALG616 |
| Description | Non-Isolated Differential Analog Input Module |
| Input Channels | 16 Single-Ended or 8 Differential |
| Voltage Range | ±10 V, 0-10 V, ±5 V, 0-5 V, 1-5 V |
| Current Range | 0-20 mA, 4-20 mA, ±20 mA |
| Resolution | 24-bit ADC |
| Power Consumption | 450 mA at 3.3 V DC, 600 mA at 5 V DC |
| Operating Temperature | 0 °C to +60 °C (32 °F to +140 °F) |
| Weight | 0.3 kg (0.66 lb) |
