Product Overview
The Emerson VE3008 DeltaV MQ Controller is a high-performance control module that facilitates communication and control between field devices and other network nodes. It offers advanced processing capabilities while maintaining compatibility with existing DeltaV™ control strategies and configurations.
Key Features
• Provides seamless communication between field devices and control network nodes.
• Same features and memory capacity as the MD Plus Controller.
• Supports redundant control networks for enhanced reliability.
• Integrated LED indicators for real-time status monitoring.
Technical Specifications
Power, Mounting, and Memory
|
Parameter |
Specification |
|---|---|
|
Power Requirement |
Supplied by System Power Supply through 2-wide Power/Controller Carrier |
|
Fuse Protection |
3.0 A, non-replaceable fuses |
|
Power Dissipation |
5.0 W typical, 7.0 W maximum |
|
Mounting |
Right slot of Power/Controller Carrier |
|
User Memory |
48 MB |
|
Primary Control Network |
8-pin RJ-45 connector |
|
Redundant Control Network |
8-pin RJ-45 connector |
LED Indicators
|
LED Status |
Description |
|---|---|
|
Green – Power |
DC power applied |
|
Red – Error |
Error condition detected |
|
Green – Active |
Operating as the primary controller |
|
Green – Standby |
Operating as a backup controller (reserved for future use) |
|
Yellow Flashing – Pri. CN |
Valid primary control network communication |
|
Yellow Flashing – Sec. CN |
Valid secondary control network communication |
|
All except Power flashing |
Controller identified via user interface software (ping command) |
|
All except Power flashing alternately |
Firmware upgrade in progress |
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Operating Temperature |
-40°C to +70°C (-40°F to +158°F) |
|
Storage Temperature |
-40°C to +85°C (-40°F to +185°F) |
|
Relative Humidity |
5% to 95%, non-condensing |
|
Airborne Contaminants |
ISA-S71.04-1985 Airborne Contaminants Class G3 (Conformal coating) |
|
Shock Resistance |
10 g ½-sine wave for 11 ms |
|
Vibration Resistance |
1 mm peak-to-peak (5 Hz to 16 Hz), 0.5 g (16 Hz to 150 Hz) |
