Product Description
Product Overview
The Emerson KJ2003X1-BB1 MD Plus Controller is a high-performance controller designed for process control applications within the DeltaV distributed control system (DCS). It provides real-time execution of control strategies, ensuring high reliability and fast communication with field devices and other system components.
Key Features
• MD Plus Controller for DeltaV DCS with robust processing capabilities.
• Optimized for demanding process control applications.
• Reliable operation in harsh industrial environments.
• Designed to withstand shock, vibration, and airborne contaminants.
• Wide operating temperature range for flexible deployment.
Technical Specifications
Power Specifications
Parameter |
Specification |
---|---|
Local Bus Power Rating |
+5 VDC at 1.4 A |
Environmental Specifications
Parameter |
Specification |
---|---|
Ambient Temperature |
-40°C to +70°C |
Shock Resistance |
10g ½ sine wave for 11 ms |
Vibration Resistance |
1 mm peak-to-peak from 5 Hz to 16 Hz 0.5g from 16 Hz to 150 Hz |
Airborne Contaminants |
ISA-S71.04-1985 Class G3 (Conformal coating) |
Relative Humidity |
5% to 95%, non-condensing |
