Product Description
Product Overview
The Emerson KJ1501X1-BK1 is an S-Series DC/DC System Power Supply, designed to deliver reliable and stable power for DeltaV automation systems. It supports multiple voltage outputs, ensuring efficient power distribution in industrial environments.
Key Features
• Wide input voltage range for flexible power configurations.
• Multiple output voltages for diverse system requirements.
• Designed for high reliability in harsh industrial environments.
Technical Specifications
System Power
|
Parameter |
Specification |
|---|---|
|
Input Power |
19.2 VDC to 28.8 VDC |
|
Output Power |
10.2 W total at 70°C |
|
Output Rating |
- 12 VDC at 8 A max (to 60°C) or 6 A max (to 70°C) - 5.1 VDC at 2.0 A - 3.4 VDC at 2.0 A |
Environmental Specifications
|
Parameter |
Specification |
|---|---|
|
Ambient Temperature |
-40°C to +70°C |
|
Shock Resistance |
10g half-sine wave for 11 ms |
|
Vibration Resistance |
1mm Peak to Peak (5–16Hz), 0.5g (16–150Hz) |
|
Airborne Contaminants |
ISA-S71.04-1985 Class G3 |
|
Relative Humidity |
5% to 95% Non-Condensing |
