Product Description
Product Details
Manufacturer: BACHMANN
Model/Part Number: DO216
Description: Digital input/output modules
Description
- Number of Outputs: 16
- Output Current / Channel: 2.5 A
- Groups with Different Power Supplies: 2 (1-8 / 9-16)
- Total Current / Group: Max. 8 A
-
Switching Delay (Resistive Load):
- 0 -> 1 (Normally 80 µs at 1 A)
- 1 -> 0 (Normally 250 µs at 1 A)
- Galvanic Isolation from System: 500 V
Ambient Conditions
- Operating Temperature: -30°C to +60°C
- Relative Humidity (Operation): 5–95% (with or without condensation)
- Storage Temperature: -40°C to +85°C
- Relative Humidity (Storage): 5–95% with condensation
Execution Variants
- Digital output module; 16x 2.5A / 24V DC outputs; 2 groups; isolated
