Product Description
General Information
|
Attribute |
Details |
|---|---|
|
Manufacturer |
Bently Nevada |
|
Series |
Not specified |
|
Model/Part Number |
991-06-XX-01-05 |
|
Model Type |
Thrust Transmitter |
Mechanical
|
Component |
Material / Specification |
|---|---|
|
Transducer Tip Material |
Polyphenylene sulfide (PPS) |
|
Transducer Case Material |
AISI 303 or 304 Stainless Steel (SST) |
|
Probe Cable |
75Ω coaxial, fluoroethylene propylene (FEP) insulated |
|
Cable Armor (Optional) |
Flexible AISI 302 SST with optional FEP outer jacket |
|
Tensile Strength |
222 N (50 lbf) probe case to probe lead, maximum |
|
Transmitter Weight |
0.43 kg (0.9 lbm) |
|
Total System Weight |
0.82 kg (1.8 lbm) typical |
Environmental Limits
|
Component |
Operating Temperature |
Storage Temperature |
|---|---|---|
|
Transmitter |
-35°C to +85°C (-31°F to +185°F) |
-51°C to +100°C (-60°F to +212°F) |
|
Probe |
-52°C to +177°C (-62°F to +351°F) |
-52°C to +177°C (-62°F to +351°F) |
|
Relative Humidity |
100% condensing, non-submerged, with protection of coaxial connectors |
Ordering Information
|
Model Number |
Description |
|---|---|
|
991-AA-BB-CC-DD |
Ordering code structure |
Options
|
Code |
Option Description |
|---|---|
|
A: Full-scale Option |
06 = 0.6-0-0.6 mm, 25 = 25-0-25 mils |
|
B: System Length Option |
50 = 5.0 meters (16.4 feet), 70 = 7.0 meters (23.0 feet) |
|
C: Mounting Option |
01 = 35 mm DIN-rail clips, 02 = Bulkhead screws, 03 = DIN clips and screws |
|
D: Agency Approval Option |
00 = Not required, 01 = CSA Division 2, 05 = CSA Division 2, ATEX Zone 0, ATEX Zone 2, ABS maritime approval |
