Product Description
Product Details
| Manufacturer | Bently Nevada |
|---|---|
| Model/Part Number | 135785-01 |
| Description | 3500/93 System Display Module |
Specifications
| Attribute | Details |
|---|---|
| Dimensions | 41.5 cm x 20.5 cm x 5 cm |
| Weight | 2.15 kg |
| Power Consumption | 15.5 watts maximum (includes Display Unit and Display Interface Module). |
| Inputs | Collects data such as current values and current alarm status via a high-speed internal network. |
| Outputs | Provides visual indication of system event lists, alarm event lists, and data from monitors, relay modules, Keyphasor modules, or tachometer modules. |
Features
| Feature | Details |
|---|---|
| Mounting Options | Face Mounting, 19-inch EIA Rack Mounting, Panel Mounting, Independent Mounting. |
| Configuration Software | Configurable using 3500 Rack Configuration Software. |
| Display Interface Module (DIM) | Required for operation and must be installed in slot 15 of the 3500 rack. |
| External Power Supply | Required for: |
| - Applications using cables longer than 100 feet. | |
| - Backlit display units. |
