Bently Nevada 3500/61 133827-02 RTD/TC Non-Isolated I/O Module External Terminations

Bently Nevada 3500/61 133827-02 RTD/TC Non-Isolated I/O Module External Terminations

  • Manufacturer: Bently Nevada

  • Product No.: 133827-02

  • Condition:1000 in stock

  • Product Type: Module External Terminations

  • Product Origin: USA

  • Payment: T/T, Western Union

  • Weight: 460g

  • Shipping port: Xiamen

  • Warranty: 12 months

  • 24/7 Support
  • 30-Day Returns
  • Fast Shipping

Product Overview

  • Manufacturer: Bently Nevada
  • Model/Part Number: 3500/61 133827-02
  • Description: RTD/TC Non-Isolated I/O Module External Terminations

Specifications

Inputs

  • Signal Type: Accepts 1 to 6 RTD (Resistance Temperature Detector) or TC (Thermocouple) transducer signals.
  • Input Impedance: 10 MΩ for each lead input.

Power Consumption

  • 3500/61 Module: Nominal consumption of 9 watts.

Transducers and Isolation

  • System Isolation: 500 Vdc
  • Channel-to-Channel Isolation: 250 Vdc
  • Notes: Isolation is required only for fault scenarios; these voltages are not present on the I/O module inputs under normal conditions.

Outputs

  • Front Panel LEDs:
    • OK LED: Indicates when the Temperature Monitor is operating properly.
    • TX/RX LED: Indicates when the Temperature Monitor is communicating with other modules in the 3500 rack.
    • Bypass LED: Indicates when the Temperature Monitor is in Bypass Mode.

Alarms

  • Alarm Setpoints:

    • Alert and Danger setpoints are adjustable using software configuration.
    • Range: Adjustable from 0 to 100% of full-scale for each measured value, unless limited by the sensor's range.
    • Accuracy: ±0.13% of the desired value.
    • Supports both under and over alarm setpoints.
  • Alarm Time Delays:

    • Alert: 1 to 60 seconds in 1-second intervals.
    • Danger: 1 to 60 seconds in 0.5-second intervals.

Measured Values

  • Description: Provides temperature measurements to monitor the machine.

Environmental Limits

Parameter Condition Temperature Range
Operating Temperature With Internal/External Termination I/O Modules -30°C to +65°C (-22°F to +150°F)
With Internal Barrier I/O Modules (Internal Termination) 0°C to +65°C (32°F to +150°F)
Storage Temperature - -40°C to +85°C (-40°F to +185°F)

Physical Dimensions

Parameter Dimensions (H x W x D) Weight
I/O Modules 241.3 mm x 24.4 mm x 99.1 mm 0.45 kg (1.0 lb)
I/O Modules (with Internal Barrier) 241.3 mm x 24.4 mm x 163.1 mm 0.46 kg (1.01 lb)
View full details

Product Description

Product Overview

  • Manufacturer: Bently Nevada
  • Model/Part Number: 3500/61 133827-02
  • Description: RTD/TC Non-Isolated I/O Module External Terminations

Specifications

Inputs

  • Signal Type: Accepts 1 to 6 RTD (Resistance Temperature Detector) or TC (Thermocouple) transducer signals.
  • Input Impedance: 10 MΩ for each lead input.

Power Consumption

  • 3500/61 Module: Nominal consumption of 9 watts.

Transducers and Isolation

  • System Isolation: 500 Vdc
  • Channel-to-Channel Isolation: 250 Vdc
  • Notes: Isolation is required only for fault scenarios; these voltages are not present on the I/O module inputs under normal conditions.

Outputs

  • Front Panel LEDs:
    • OK LED: Indicates when the Temperature Monitor is operating properly.
    • TX/RX LED: Indicates when the Temperature Monitor is communicating with other modules in the 3500 rack.
    • Bypass LED: Indicates when the Temperature Monitor is in Bypass Mode.

Alarms

  • Alarm Setpoints:

    • Alert and Danger setpoints are adjustable using software configuration.
    • Range: Adjustable from 0 to 100% of full-scale for each measured value, unless limited by the sensor's range.
    • Accuracy: ±0.13% of the desired value.
    • Supports both under and over alarm setpoints.
  • Alarm Time Delays:

    • Alert: 1 to 60 seconds in 1-second intervals.
    • Danger: 1 to 60 seconds in 0.5-second intervals.

Measured Values

  • Description: Provides temperature measurements to monitor the machine.

Environmental Limits

Parameter Condition Temperature Range
Operating Temperature With Internal/External Termination I/O Modules -30°C to +65°C (-22°F to +150°F)
With Internal Barrier I/O Modules (Internal Termination) 0°C to +65°C (32°F to +150°F)
Storage Temperature - -40°C to +85°C (-40°F to +185°F)

Physical Dimensions

Parameter Dimensions (H x W x D) Weight
I/O Modules 241.3 mm x 24.4 mm x 99.1 mm 0.45 kg (1.0 lb)
I/O Modules (with Internal Barrier) 241.3 mm x 24.4 mm x 163.1 mm 0.46 kg (1.01 lb)

Download PDF file here:

Click to Download PDF
