Product Description
Product Details
- Manufacturer: Bently Nevada
- Model/Part Number: 3500/42-01-00
- Description: 3500/42M Proximitor Seismic Monitor
Description
The 3500/42M Proximitor Seismic Monitor is designed to:
- Protect machinery by continuously monitoring parameters and comparing them against user-configured alarm setpoints.
- Communicate critical machine information to operations and maintenance teams for effective monitoring and decision-making.
Environmental Limits
-
Operating Temperature:
- With Internal/External Termination I/O Module:
- -30°C to +65°C (-22°F to +150°F)
- With Internal Barrier I/O Module (Internal Termination):
- 0°C to +65°C (32°F to +150°F)
- With Internal/External Termination I/O Module:
-
Storage Temperature:
- -40°C to +85°C (-40°F to +185°F)
- Humidity: 95%, non-condensing
Physical Specifications
-
Monitor Module Dimensions (Height x Width x Depth):
- 241.3 mm x 24.4 mm x 241.8 mm
- (9.50 in x 0.96 in x 9.52 in)
- Weight: 0.91 kg (2.0 lb)
Ordering Information
Monitor Configuration:
3500/42-AA-BB
- A: I/O Module Type (See available I/O module types in the product documentation).
-
B: Hazardous Area Approval Option:
- 00: None
- 01: cNRTLus (Class 1, Division 2)
- 02: ATEX / IECEx / CSA (Class 1, Zone 2)
