Product Description
Product Details
- Manufacturer: Bently Nevada
- Model/Part Number: 176449-01
- Description: Proximitor Monitor
Specifications
| Attribute | Details |
|---|---|
| Inputs | Accepts from 1 to 4 proximity transducer signals |
| Power Consumption | 7.7 Watts, typical |
| Input Impedance | Standard I/O: 10 kΩ (Proximitor and acceleration inputs) |
Ordering Information
| Attribute | Details |
|---|---|
| Proximitor Monitor Model Options | 3500/40M-AA-BB |
| A: I/O Module Type | 01: Proximitor I/O Module with Internal Termination |
| 02: Proximitor I/O Module with External Terminations | |
| 03: Proximitor I/O Module with Internal Barriers and Internal Terminations | |
| B: Hazardous Area Approval Option | 00: None |
| 01: cNRTLus (Class 1, Division 2) | |
| 02: ATEX / IECEx / CSA (Class 1, Zone 2) |
Environmental Limits
| Attribute | Details |
|---|---|
| Operating Temperature | When used with Internal/External Termination I/O Module: -30°C to +65°C (-22°F to +150°F) |
| When used with Internal Barrier I/O Module (Internal Termination): 0°C to +65°C (32°F to +150°F) | |
| Storage Temperature | -40°C to +85°C (-40°F to +185°F) |
| Humidity | 95%, non-condensing |
Physical
| Attribute | Details |
|---|---|
| Monitor Module Dimensions | Height x Width x Depth: 241.3 mm x 24.4 mm x 241.8 mm (9.50 in x 0.96 in x 9.52 in) |
| Weight | 0.91 kg (2.0 lb) |
