Product Description
General Information
-
Manufacturer: Bently Nevada
-
Series: 3300
-
Model/Part Number: 330930-065-09-05
-
Model Type: 3300 NSv Extension Cable
Specifications
Electrical
| Attribute | Value |
|---|---|
| Proximitor Sensor Input | Accepts one non-contacting 3300 RAM or 3300 NSv Proximity Probe and Extension Cable |
| Extension Cable DC Resistance |
Center conductor: 0.220 Ω/m (0.067 Ω/ft) Shield: 0.066 Ω/m (0.020 Ω/ft) |
| Extension Cable Capacitance | 69.9 pF/m (21.3 pF/ft) typical |
| Extension Cable Material | 75 Ω coaxial, fluoroethylene propylene (FEP) insulated |
| Proximitor Sensor Material | A380 aluminum |
Dimensions and Weight
| Attribute | Value |
|---|---|
| System Length | 5 or 7 meters (including extension cable) |
| Extension Cable Weight | 45 g/m (0.5 oz/ft) without armor, 64 g/m (0.7 oz/ft) with armor |
Temperature and Humidity Limits
| Attribute | Value |
|---|---|
| Extension Cable Temperature Range | -52°C to +177°C (-62°F to +351°F) |
| Proximitor Sensor Temperature Range | Operating: -52°C to +100°C (-62°F to +212°F) Storage: -52°C to +105°C (-62°F to +221°F) |
| Relative Humidity | 100% condensing, non-submersible when connectors are protected. Tested to IEC 68-2-3 damp heat |
Ordering Information for Extension Cable
3300 NSv Extension Cable (330930-AAA-BB-CC)
A: Cable Length Option
-
040 → 4.0 meters (13.1 feet)
-
045 → 4.5 meters (14.8 feet)
-
060 → 6.0 meters (19.7 feet)
-
065 → 6.5 meters (21.3 feet)
B: Connector and Cable Option
-
00 → Without stainless steel armor
-
01 → With stainless steel armor, with FEP jacket
-
02 → With stainless steel armor, without FEP jacket
-
03 → Without stainless steel armor, with connector protector
-
04 → With stainless steel armor, with FEP jacket, with connector protector
-
05 → With stainless steel armor, without FEP jacket, with connector protector
-
06 → FluidLoc cable without stainless steel armor
-
07 → FluidLoc cable with stainless steel armor, with FEP jacket
-
08 → FluidLoc cable with stainless steel armor, without FEP jacket
-
09 → FluidLoc without stainless steel armor, with connector protector
-
10 → FluidLoc cable with stainless steel armor, with FEP jacket, with connector protector
-
11 → FluidLoc cable with stainless steel armor, without FEP jacket, with connector protector
C: Agency Approval Option
-
00 → Not Required
-
05 → Multiple Approvals
