Product Description
Product Details
- Manufacturer: Bently Nevada
- Model/Part Number: 330930-065-00-CN
- Description: 3300 NSv Extension Cable
Specifications
Model Options
-
Part Number: 330930-AAA-BB-CC
-
A (Cable Length Option):
- 040: 4.0 meters (13.1 feet)
- 045: 4.5 meters (14.8 feet)
- 060: 6.0 meters (19.7 feet)
- 065: 6.5 meters (21.3 feet)
-
B (Connector and Cable Option):
- 00: Without stainless steel armor
- 01: With stainless steel armor, with FEP jacket
- 02: With stainless steel armor, without FEP jacket
- 03: Without stainless steel armor, with connector protector
- 04: With stainless steel armor, with FEP jacket, with connector protector
- 05: With stainless steel armor, without FEP jacket, with connector protector
- 06: FluidLoc cable without stainless steel armor
- 07: FluidLoc cable with stainless steel armor, with FEP jacket
- 08: FluidLoc cable with stainless steel armor, without FEP jacket
- 09: FluidLoc without stainless steel armor, with connector protector
- 10: FluidLoc cable with stainless steel armor, with FEP jacket, with connector protector
- 11: FluidLoc cable with stainless steel armor, without FEP jacket, with connector protector
-
C (Agency Approval Option):
- 00: Not required
- 05: Multiple Approvals
-
A (Cable Length Option):
System Weight (Typical)
| Component | Weight |
|---|---|
| Probe | Approximately 14 to 150 g (0.5 to 5.3 oz) |
| Extension Cable | 45 g/m (0.5 oz/ft) |
| Armored Extension Cable | 64 g/m (0.7 oz/ft) |
| Proximitor Sensor | 255 g (9 oz) |
Thread Engagement Limits
| Thread Type | Maximum Length of Engagement |
|---|---|
| 1/4-28 | 0.375 in |
| 3/8-24 | 0.563 in |
| M8x1 | 12 mm |
| M10x1 | 15 mm |
Environmental Limits
| Component | Operating Temperature | Storage Temperature |
|---|---|---|
| Probe | -52°C to +177°C (-62°F to +351°F) | -52°C to +177°C (-62°F to +351°F) |
| Extension Cable | -52°C to +177°C (-62°F to +351°F) | -52°C to +177°C (-62°F to +351°F) |
| Proximitor Sensor | -52°C to +100°C (-62°F to +212°F) | -52°C to +105°C (-62°F to +221°F) |
- Relative Humidity: 100% condensing, non-submersible when connectors are protected.
- Test Standard: Tested to IEC 68-2-3 damp heat
