Product Description
🔹 General Information
|
Manufacturer |
Bently Nevada |
|---|---|
|
Series |
– |
|
Model/Part Number |
330500-01-04 |
|
Description |
330500 Velomitor Piezo-velocity Sensor |
🔹 Description
The 330500 Velomitor is a piezoelectric-based velocity sensor designed to measure absolute casing, bearing housing, or structural vibration. It includes integrated electronics in a robust, solid-state hermetically sealed package for industrial environments.
🔹 Environmental Limits
|
Parameter |
Specification |
|---|---|
|
Operating Temperature |
-55°C to +121°C (-67°F to +250°F) |
|
Shock Survivability |
5,000 g peak |
|
Relative Humidity |
To 100%, non-submerged; hermetically sealed |
|
Base Strain Sensitivity |
0.005 in/s/mstrain |
|
Magnetic Field Susceptibility |
<51 min/s/gauss (at 50 gauss, 50–60 Hz) |
🔹 Physical
|
Item |
Specification |
|---|---|
|
Weight |
142 g (5.0 oz), typical |
|
Diameter |
25.3 mm (0.995 in) |
|
Height |
63.2 mm (2.49 in) |
🔹 Ordering Information Breakdown – Model:
330500-01-04
|
Field |
Code |
Description |
|---|---|---|
|
A |
01 |
Mounting Thread Adapter: 1/2 - 20 UNF |
|
B |
04 |
Multiple Approvals: CSA, ATEX |
